Feeders,Stackers,Vacuum Conveyors,Inserters,Perforators,Label Feeders,Die Cutters,Rewinders

Inline Batch Gluers

Originally designed for the Draw/Ticket business, this unit will slide under the delivery end of a printing press and collect the printed and numbered sheets. Automatically gluing them together into booklets of a predetermined number and applying a cover sheet to each booklet.

Offline Batch Gluers

Attached to a numbering machine Auto Feeders batch gluer will collate pre-printed sheets into predetermined sets, by applying lines of glue dots to the sheets giving the appearance of the books being stitched together. Just enter in the counter the amount of tickets required in a booklet. It will then inhibit the glue on the top page of each booklet.

Card/Label Friction Feeders

Feeds paper, card, books, magazines, leaflets, folded labels, etc. from the bottom of the pile with friction belts.

Speeds up to 32,000 per hour
Sheet sizes from 30mm square up to A4
Maximum Pile height 700mm

Sheet Feeders

Sheet feeders for Paper, Board, Card, Plastics.

Speeds up to 8,500 sheets per hour
Sheet sizes from A4 to 1200 mm square
Feed heights from 800 to 1,500mm
Pile weight 1200 Kg

Sheet Stackers

To stand at the end of a processing line and collect the sheets automatically stacking them neatly onto a pallet.

Speeds up to 8,000 per hour single or 16,000 shingled
Sheet sizes from A4 up to 1,200mm square
Maximum pile weight 1,200 kg

Sheet Inserters

Sheet Inserters are designed to introduce sheets into the main flow of sheets on a printing or other type of production line. This may be in order to protect a product as in printed circuit boards or as an additional sheet such as backing or cover sheets in pads.

Label Rewinders

Label Rewinders for Counting, Joining, Inspecting, Reversing.

Special Purpose

All of our specialised machinery is built to order.

Label Die Cutters

Label Die Cutters- The machine is supplied with six slitting knives to divide the web into five reels which are wound up side by side. More knives can be fitted as required. A splicing table is mounted above the unwind shaft and is fitted with integral clamps.
